Y 15°
λ 40°
z=4
ø
3÷20
HM MG10
| aplikace | doporučené | použitelné | |
|---|---|---|---|
| <850 N/mm2 | <25 HRC | Nerez | Alu |
| <1200 N/mm2 | <40 HRC | Litina |
| hrubování | dokončování |
|---|---|
| TripleCoating Cr | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| ød1 h10 | l2 | l1 | l3 | ød3 | ød2 h5 | z | Obj. číslo | € | Kč |
| 3 | 4 | 57 | 14 | 2,8 | 6 | 4 | 113710T.0304 | 26,21 | 637 |
| 3 | 8 | 57 | 14 | 2,8 | 6 | 4 | 113710T.0308 | 26,21 | 637 |
| 4 | 5 | 57 | 16 | 3,8 | 6 | 4 | 113710T.0405 | 26,99 | 656 |
| 4 | 11 | 57 | 16 | 3,8 | 6 | 4 | 113710T.0411 | 26,99 | 656 |
| 5 | 6 | 57 | 18 | 4,7 | 6 | 4 | 113710T.0506 | 27,73 | 674 |
| 5 | 13 | 57 | 18 | 4,7 | 6 | 4 | 113710T.0513 | 27,73 | 674 |
| 6 | 7 | 57 | 20 | 5,7 | 6 | 4 | 113710T.0607 | 26,21 | 637 |
| 6 | 13 | 57 | 20 | 5,7 | 6 | 4 | 113710T.0613 | 26,21 | 637 |
| 8 | 9 | 63 | 26 | 7,6 | 8 | 4 | 113710T.0809 | 36,25 | 881 |
| 8 | 19 | 63 | 26 | 7,6 | 8 | 4 | 113710T.0819 | 36,25 | 881 |
| 10 | 11 | 72 | 31 | 9,6 | 10 | 4 | 113710T.1011 | 50,20 | 1 220 |
| 10 | 22 | 72 | 31 | 9,6 | 10 | 4 | 113710T.1022 | 50,20 | 1 220 |
| 12 | 13 | 83 | 37 | 11,5 | 12 | 4 | 113710T.1213 | 69,87 | 1 698 |
| 12 | 26 | 83 | 37 | 11,5 | 12 | 4 | 113710T.1226 | 69,87 | 1 698 |
| 14 | 15 | 83 | 37 | 13,5 | 14 | 4 | 113710T.1415 | 92,05 | 2 237 |
| 14 | 26 | 83 | 37 | 13,5 | 14 | 4 | 113710T.1426 | 92,05 | 2 237 |
| 16 | 17 | 92 | 43 | 15,5 | 16 | 4 | 113710T.1617 | 111,23 | 2 703 |
| 16 | 32 | 92 | 43 | 15,5 | 16 | 4 | 113710T.1632 | 111,23 | 2 703 |
| 18 | 19 | 92 | 43 | 17,4 | 18 | 4 | 113710T.1819 | 141,64 | 3 442 |
| 18 | 32 | 92 | 43 | 17,4 | 18 | 4 | 113710T.1832 | 141,64 | 3 442 |
| 20 | 21 | 104 | 53 | 19,4 | 20 | 4 | 113710T.2021 | 181,60 | 4 413 |
| 20 | 38 | 104 | 53 | 19,4 | 20 | 4 | 113710T.2038 | 181,60 | 4 413 |
| Skladem, na objednávku 24h | |||||||||
další rozměry dle požadavku
weldon / DIN 6535 HB dle požadavku
rohový rádius dle požadavku
příklad objednávky: 113710T.0304 – 5 ks
